20 Rockwell Automation Publication 1715-UM001J-EN-P - December 2020
Chapter 1 Redundancy System Overview
Figure 4 - Shield Termination Arrangement to prevent Ground Loops
This complies with the shield grounding guidance given in The CIP Networks
Library, Volume 2, Edition 1.21, section 8-9.4.3. ©ODVA, Inc. 2016.
For more information regarding ODVA, visit www.odva.org
.
Simplex Architecture
Simplex I/O modules fail-safe on the first detected module fault. The process
under control shuts down when the fault is detected.
This configuration is suitable for high and low demand module applications.
Resistor
RJ 45
Shield
Transient
Protection
Device
Capacitor
