Rockwell Automation Allen-Bradley 1715-IF16 User Manual

58 Rockwell Automation Publication 1715-UM001J-EN-P - December 2020
Chapter 2 Installation Instructions
Component Size and Weights
The total depth of a base unit and module is 136 mm (5.375 in.).
Figure 24 - Module Dimensions
All module dimensions are the same, whether they are adapters or I/O
modules.
Table 6 - Component Sizes
Item Size (H x W x D)
Adapter base unit 224 x 84 x 30 mm (8.82 x 3.31 x 1.18 in.)
I/O module base unit 233 x 126 x 18 mm (9.25 x 5 x 0.75 in.)
Module 166 x 42 x 118 mm (6.5 x 1.625 x 4.625 in.)
32067 M
