284 Rockwell Automation Publication 1715-UM001J-EN-P - December 2020
Appendix F I/O Tag Definitions
1715-IF16 This section describes the tags that are associated with the 1715-IF16 module.
ModBFieldPowerVoltage2 DINT
Reports the voltage from the field power supply for the specified module and field power input.
Accuracy is ± 500mV
Ch AB_1715_ChStatusStruc:I:0[8]
Current / Voltage
Status Array
Each element of the array
comprises
Current: REAL
Reports the current for the channel in
milliamps and with an accuracy of ± 2
mA and ± 10% of measurement
Voltage: REAL
Reports the channel voltage at the
output terminals in units of millivolts
and with an accuracy of ± 500 mV (The
voltage element cannot report values
below 0 mV
Table 68 - 8-channel Digital Output, Duplex, Input
Tag Name Data Type Definition
Table 69 - 16-channel Analog Input, Simplex, Input
Tag Name Data Type Definition
Fault DINT, Binary Module fault bit:
0 when one module is present and reporting valid data, OxFFF_FFFF
when no modules are present, no Logix connection exists, or reported
data is invalid.
ChSimplex[0 - 15] Array of structure Array of 16 structures that represent the data and fault status for channels 0…15:
Data REAL Input data status
Faults DINT, bit-field Channel fault status:
Bit Name Description
0 Fault 0 = Good
1 = Circuit fault for this channel
3 Underrange 0 = Good
1 = Underrange detected
4 Overrange 0 = Good
1 = Overrange detected
RollingTimestamp INT Timestamp data
Status DINT, bit-field Bit Name Description
8 GroupFault 0 = Good
1 = Any channel on the module is
faulted/failed
Table 70 - 16-channel Analog Input, Duplex, Input
Tag Name Data Type Definition
Fault DINT, Binary Module fault bit:
0 when one module is present and reporting valid data, OxFFF_FFFF
when no modules are present, no Logix connection exits, or reported
data is invalid.
ChSimplex[0…15] Array of structure Array of 16 structures that represent the data and fault status for channels 0…15:
0 = Data
1 = Faults
Data REAL Input data
Faults DINT, bit-field Channel fault status:
Bit Name Description
0 Fault 0 = Good
1 = Circuit fault for this channel
1 ModAFault 0 = Good
1 = This channel on Module A is
faulted/failed
2 ModBFault 0 = Good
