Rockwell Automation Publication 1715-UM001J-EN-P - December 2020 45
Chapter 2 Installation Instructions
Digital Input Termination Assemblies
Digital input termination assemblies support these features:
• 16-channel simplex TA provides termination for 16 digital input channels
• Industry-standard field device connections at terminal blocks
• 24V DC digital input channels with a load of 5.11 k
per input channel
• Individually fused channels with over voltage input protection
There are two types of digital input termination assemblies:
• A 1715-TASIB16D, 16-channel simplex TA that provides termination for 16
digital input channels and mates with one 1715-IB16D digital input
module
• A 1715-TADIB16D, 16-channel duplex TA that provides termination for 16
digital input channels and mates with up to two 1715-IB16D digital input
modules
1715-IF16
1715-TASIF16 Analog input simplex
1715-TADIF16 Analog input duplex
1715-OF8I
1715-TASOF8 Analog output simplex
1715-TADOF8 Analog output duplex
Table 5 - I/O Termination Assembly Descriptions
I/O Module Termination Assembly Cat. No. Termination Assembly Description
