Rockwell Automation Publication 1715-UM001J-EN-P - December 2020 167

Chapter 6 Configure the Redundant I/O System

2. Expand the Communications list, select the 1715-AENTR module, and

click OK.

The redundant Module Properties dialog box appears.

3. Name the module, enter the IP address.

The Slot numbers for the adapters are always 0 and 1.
