70 Rockwell Automation Publication 1715-UM001J-EN-P - December 2020

Chapter 2 Installation Instructions

2. When installing the cable on the left side of the base unit, insert a cable

socket assembly into the I/O backplane connector.

3. Insert an M3 nut into the base unit molding assembly as shown.

32081 M
