76 Rockwell Automation Publication 1715-UM001J-EN-P - December 2020

Chapter 2 Installation Instructions

Figure 32 - Line Monitored Inputs

Threshold Settings for Line Monitored Field Devices

For information about setting threshold values, see Threshold Values for

Digital Inputs on page 299.

It is recommended that you do a manual calibration drift check every two

years. See Calibration Drift Checks on page 311 .

5.11

32114 M
