Rockwell Automation Publication 1715-UM001J-EN-P - December 2020 95
Chapter 2 Installation Instructions
Field Wiring of Analog Output Termination Assemblies
Figure 55 - 1715-TASOF8 and 1715-TADOF8 Analog Output Termination Assemblies
Analog Output Slew Tolerance
Analog output channel voltage slew is unconstrained with the limits set by the
compliance operating voltage range of the module.
Field Loop Circuit for Analog Outputs
The field loop circuit for an analog output is shown in Figure 56.
CH
LOOP-
DAOTA
PCB130861 REV A
LOOP+
TB1
J1 J2 J4
J3
01
TB2
23
TB3
45
TB4
67
32122 M
1715-TADOF8
Analog Output Duplex
Termination Assembly
1715-TASOF8
Analog Output Simplex
Termination Assembly
32123 M
Field Connections This Side
Field Connections This Side
J1 J2
cc
CH0 1 2 3 4 5 6 7
Fuse Cover
Fuse Covers
Coding Pegs
Coding Pegs
To Next Page
