Rockwell Automation Allen-Bradley IMPACT 1336 Series

5–3Part Replacement Procedures
Publication 1336 IMPACT-6.8 – November, 2002
Figure 5.2
Exploded View of Inverter Bay
Power Module
Ground
Fault CT
Power Module Gate
Interface Board
Bus Fuse
Bus
Capacitors
L Option
Board
Control
Board
Common Bus
Precharge Board
Gate Driver
Board
Power Module
Snubber Board
Thermistor
Power Module
Snubber Resistor
Fan 1
Fan 2
Volt-Sharing
Resistor and
Dual Diodes
Diode w/
Heat Sink
SCR w/
Heat Sink
Thermostat
Input Rectifier
Snubber Board
Power
Supply
Current
Transducer
(LEM)
