3–22 Access Procedures
Publication 1336 IMPACT-6.8 – November, 2002
Installation
Install the Capacitor Bank Assembly in reverse order of removal.
Refer to Table 3.A – Fastener Torque Specifications in this chapter.
Important: Guide the unit into place so that it mates with the
lock-down bolt at the top of the capacitor frame. Adjust
the angle brackets at the ends of the T bar crossbar.
!
ATTENTION: Replace all guards before applying
power to the drive. Failure to replace guards may result
in death or serious injury.
