5–24 Part Replacement Procedures
Publication 1336 IMPACT-6.8 – November, 2002
Figure 5.12
Power Module Snubber Resistor
AB0642A
Power Module
Snubber Resistor
Main Heat Sink
Screw
J1
J2
Screw
Inverter Assembly w/o Cabinet
Installation
Install the Power Module Snubber Resistor in reverse order of
removal.
Important: Install the resistors with the markings to the right
(outside) for easier future reference.
!
ATTENTION: Replace all guards before applying
power to the drive. Failure to replace guards may result
in death or serious injury.
