3–27Access Procedures
Publication 1336 IMPACT-6.8 – November, 2002
!
ATTENTION: Hazard of tipping and severe injury
exists. This process requires two people. The platform
must be able to support 900 kg (2,000 lbs).
8. Referring to Figure 3.16, pull the assembly onto a user-supplied
platform. Pull using the handle attached to the Fan 2 housing.
Installation
Install the Inverter Assembly in reverse order of removal. Refer to
Table 3.A – Fastener Torque Specifications in this chapter.
Important: When pushing the Inverter Assembly into the drive, you
may need to have someone tip the unit slightly to the
left or right to center it between the guides at the back
of the Enclosure. Adjust the angle brackets at the ends
of the T bar crossbar.
!
ATTENTION: Replace all guards before applying
power to the drive. Failure to replace guards may result
in death or serious injury.
