3–16 Access Procedures
Publication 1336 IMPACT-6.8 – November, 2002
Important: The motor buses include a Common Mode Choke,
which can only be replaced as part of the Motor Bus
assembly.
Installation
Install the Motor Bus Bars in reverse order of removal. Refer to
Table 3.A – Fastener Torque Specifications in this chapter.
!
ATTENTION: Replace all guards before applying
power to the drive. Failure to replace guards may result
in death or serious injury.
