3–9Access Procedures
Publication 1336 IMPACT-6.8 – November, 2002
Figure 3.6
Typical Check for No Incoming Voltage
Converter Bay
Fuse F1, F1A, F2, F2A, F3, F3A
Closing the Drive Enclosure
!
ATTENTION: Replace all guards before applying
power to the drive. Failure to replace guards may result
in death or serious injury.
1. If open, close and latch the Precharge Board Mounting Frame.
2. Close the Inverter Bay door and latch with quarter turn latches.
3. Close the Converter Bay door and latch with quarter turn latches.
