Preface P–3
Publication 1336 IMPACT-6.8 – November, 2002
Drive Nameplate Location
The system nameplate is located on the right side of the Converter
Bay. The system nameplate contains the drive’s catalog number and
other important drive information. Reference the catalog number
when ordering replacement parts. Another nameplate, for the
Inverter, is located on the face of the Precharge Board Mounting
Frame.
Figure P.1
Drive Nameplate Locations
Inverter Nameplate
Located on Bottom of
Precharge Board
Mounting Frame
System Nameplate
Located on Inside Wall
Inverter Bay
Converter Bay
DATA NAMEPLATE
CAT
NO
SERIAL
NO.
ORDER
NO.
3-PHASE AC OUTPUT
WIRING
DIA.
ENCLOSEMENT TYPE
CONSTANT
TORQUE
VARIABLE
TORQUE
H.P.
MAXIMUM RMS SHORT CIRCUIT CURRENT
AMPS
Allen-Bradley
KVA VOLTS HZ AMPS
KVA VOLTS HZAPH
AC INPUT
AC OUTPUT
DC INPUT
KVA VOLTS HZAPH
CONSTANT TORQUE
VARIABLE TORQUE
CAT
Allen-Bradley
3-PHASE AC INPUT
KVA VOLTS HZ AMPS
POWER RATINGS
FACILITY
The following is an explanation of the catalog numbering system for
1336 IMPACT Adjustable Frequency AC Drives and options. The
catalog number is coded to identify the drive power rating and can be
found on the drive nameplate and on the shipping carton.
