Opening the Drive Enclosure
Follow all steps in this procedure whenever you open the drive
cabinet.
Figure 3.4
Drive Enclosure
AB1089
Precharge Board Mounting
Frame Latches
1/4 Turn Door
Latches (5)
Inverter Bay
Door
Converter
Bay Door
