5–12 Part Replacement Procedures
Publication 1336 IMPACT-6.8 – November, 2002
2. Install the Common Bus Precharge Board in reverse order of
removal.
!
ATTENTION: When installing the wire harness
connecting Gate Driver Board connector J9 to
Common Bus Precharge Board connector J3, align the
wires on the harness terminals with the pins on the
board connectors. Incorrect harness connection may
result in faulty drive operation and may damage the
equipment.
!
ATTENTION: Replace all guards before applying
power to the drive. Failure to replace guards may result
in death or serious injury.
