5–41Part Replacement Procedures
Publication 1336 IMPACT-6.8 – November, 2002
!
ATTENTION: Capacitors not installed correctly will
explode or vent and may cause death or serious injury.
Observe correct polarities.
Figure 5.23
Volt-Sharing Resistor Connections to Bus Capacitors
AB0625A
R4 – R6
C13 – C24
C25 – C36
R7 – R9
C5
C9
–
CAP DETAIL
575V
R3
C10 C11 C12
C6 C7 C8
R2
C1 C2 C3 C4
R1
+
F3
D2
F2
F1
D1
C41
C40
X
C1 C2 C3 C4
C8C7C6C5
R1
R2
CAP DETAIL
480V
C9 – C16
R3 – R4
C17 – C24
R5 – R6
D1
D2
F2
F1
F3
+
–
C40
C41
X
–
–
!
ATTENTION: Replace all guards before applying
power to the drive. Failure to replace guards may result
in death or serious injury.
