1–2 Control Logic Wiring and Adapters
Publication 1336 IMPACT-6.8 – November, 2002
Figure 1.1
TB3 Terminal Block Location
Control
Board
L Option
Board
TB3 Terminal
Block
!
ATTENTION: The National Electric Code (NEC)
and local codes outline provisions for safely installing
electrical equipment. Installation must comply with
specifications regarding wire types, conductor sizes,
branch circuit protection and disconnect devices.
Failure to do so may result in personal injury and/or
equipment damage.
