2–15Troubleshooting and Error Codes
Publication 1336 IMPACT-6.8 – November, 2002
Fault Code and
Text
Suggested ActionDescription
Fault
Type
LED Status
12069
Open Circuit
CP, Solid green Warning
The fast flux up current is less than 50%
of commanded.
Make sure the motor is properly connected.
Refer to the Understanding Precharge and
Ridethrough Faults section in the
troubleshooting chapter of the user manual for
more information.
If you do not want this condition to be reported
as a warning, change bit 5 in Warning Select 1
(parameter 21) to 0.
13000
HW Malfunction
CP, Solid red Hard A hardware malfunction occurred.
Recycle the power. If the fault does not clear,
replace the Control Board.
13001
HW Malfunction
CP, Solid red Hard A hardware malfunction occurred.
Recycle the power. If the fault does not clear,
replace the Control Board.
13002
HW Malfunction
CP, Solid red Hard A hardware malfunction occurred.
Recycle the power. If the fault does not clear,
replace the Control Board.
13003
HW Malfunction
CP, Solid red Hard A hardware malfunction occurred.
Recycle the power. If the fault does not clear,
replace the Control Board.
13004
HW Malfunction
CP, Solid red Hard A hardware malfunction occurred.
Recycle the power. If the fault does not clear,
replace the Control Board.
