Rockwell Automation Publication 750-TG100B-EN-P - June 2019 117

Frame 7 Components Chapter 6

13. For the line side converter power module, remove the six M8 x 30 mm torx

screws that secure the AC input flexible bus bars to the AC input terminals

on the power module, and remove the flexible bus bars.

M8 x 30 mm

T40

19.8 N•m (175 lb•in)
