Rockwell Automation Publication 750-TG100B-EN-P - June 2019 225

Power Bay Components Chapter 9

4. Loosen the two M6 x 16 mm torx screws that secure the side guards to the

enclosure.

5. Loosen the two M6 x 16 mm torx screws that secure the bottom guard to

the enclosure.

4, 5

M6 x 16 mm

T30

4.8 N•m (42 lb•in)
