226 Rockwell Automation Publication 750-TG100B-EN-P - June 2019

Chapter 9 Power Bay Components

6. Disconnect connector P13 from J13 on the DC precharge module.

7. If present, disconnect connector P12 from J12 on the DC precharge

module.
