Specifications and Site Requirements
Mechanical Specifications
132 MagneMotion
Rockwell Automation Publication MMI-UM007F-EN-P - September 2020
NOTE: Contact ICT Customer Support for current detail drawings.
Ingress Protection Rating: IP50 (IP68 optional)
Exposed Materials
• Low Carbon Steel.
• Hardened Steel.
• Nd-Fe-B magnets with Ni-Cu-Ni coating.
• 304 Stainless Steel, 18-8 Stainless Steel.
7 838 mm [33.0 in] 15.42 kg [34.0 lb]
8 958 mm [37.7 in] 17.6 kg [38.8 lb]
* All weights are estimated based on the weight of the 7 cycle
array.
Table 4-1: High Flux Magnet Array Weights (Continued)
Cycles Length Weight
*
To Next Page
