Rockwell Automation MagneMotion QuickStick HT User Manual

Design Guidelines
Transport System Design
QuickStick HT User Manual 77
Rockwell Automation Publication MMI-UM007F-EN-P - September 2020
Figure 3-11: System Wiring Block Diagram, QSMC Connections
DOWNSTREAM
FROM LAST MOTOR/CONTROLLER DOWNSTREAM TO NEXT MOTOR/CONTROLLER DOWNSTREAM
UPSTREAM
QSHT MOTOR, 1M
700-1483-00
QSHT MOTOR, 1/2M
700-1483-01
DOWNSTREAM
SENSEDRIVEGND SENSEDRIVEGND
UPSTREAM
NC LITE
700-0871-00
JUNCTION
BOX
JUNCTION
BOX
NC-S
MMI-NC-SER08-01
AC POWER
DC POWER BUS
RS-422 110-0002-00 (can be extended using 100-2090-XX)
RS-422
110-0003-00
(can be extended
using 100-2090-XX)
DC POWER CABLE
100-2384-00
(TYPICAL TO EACH
MOTOR CONTROLLER)
RS-422 110-0090-XX
RS-422 110-0090-XX
RS-422
110-0090-XX
1/2 MSENSE 100-2386-XX
1/2 M DRIVE
700-1550-XX
1 M SENSE
100-2386-XX
1 M DRIVE
700-1537-XX
ETHERNET
SWITCH
+7 – 18 VDC OPTIONAL POE (+18 VDC)
+24 VDC
+24 VDC
+24 VDC
+24 – 48 VDC
USER COMPONENTS
MAGNEMOTION COMPONENTS
HOST CONTROLLER
HUMAN
MACHINE
INTERFACE
UTP-CAT5
UTP-CAT5
UTP-CAT5
LAN
CONSOLE
PWR
RS-422
NETWORK
POWER
CONSOLE
1234
RS-422
1234
5678
QSMC
700-1563-00
QSMC 2
700-1384-01
STATOR DRIVE GND HVDC STATOR SENSE ETHERNET UPSTREAM DOWNSTREAM LVDC
STATOR DRIVE 1 STATOR SRIVE 2 GND HVDC STATOR SENSE 1 STATOR SENSE 2 ETHERNET UPSTREAM DOWNSTREAM LVD C
