Rockwell Automation MagneMotion QuickStick HT User Manual

Specifications and Site Requirements
Electrical Specifications
156 MagneMotion
Rockwell Automation Publication MMI-UM007F-EN-P - September 2020
Stator Sense B Magnet array position sense 10 Pin, Terminal Block
Digital In 4 digital inputs DE-15, Female
Ground Ground Phillips head screw
Stator Inverter Output A 8.9 kW@ 324–528V rms,
three-phase, 13.0 A rms continu-
ous, 20 A max
4 Pin Terminal Block
Stator Inverter Output B 8.9 kW@ 324–528V rms,
three-phase, 13.0 A rms continu-
ous, 20 A max
4 Pin Terminal Block
Table 4-34: QSHT 5700 Inverter Controls
Label Description Control Type
Display Navigation Navigation controls for LCD display using soft menus Push Button
Table 4-35: QSHT 5700 Inverter Indicators
Label Description Indicator Type
Module Status Displays control power status Red/Green LED
Network Status Displays network connection status Red/Green LED
LCD Display Displays general module status LCD Display
Table 4-33: QSHT 5700 Inverter Connections (Continued)
Label Description Connector Type

Rockwell Automation MagneMotion QuickStick HT Specifications

General

Brand	Rockwell Automation
Model	MagneMotion QuickStick HT
Category	Accessories
Language	English
