Remote Control Commands
R&S
®
Scope Rider RTH
303User Manual 1326.1578.02 ─ 12
Suffix:
<m>
.
1|2 (RTH1002) , 1..4 (RTH1004)
Parameters:
<BandwidthLimit> FULL | B350 | B200 | B100 | B60 | B50 | B40 | B20 | B10 | B5 |
B4 | B2 | B1 | B5HK | B4HK | B2HK | B1HK | B50K | B40K |
B20K | B10K | B5K | B4K | B2K | B1K
FULL
At full bandwidth, all frequencies in the specified range are
acquired and displayed.
B350 | B200 | B100 | B60 | B50 | B40 | B20 | B10 | B5 | B4 | B2
| B1
Limit to 350 MHz, 200 MHz, 100 MHz, 60 MHz,..., respectively.
B5HK | B4HK | B2HK | B1HK | B50K | B40K | B20K | B10K |
B5K | B4K | B2K | B1K
Limit to 500 kHz, 400 kHz,..., respectively.
*RST:
FULL
CHANnel<m>:DESKew <Deskew>
Sets a delay for the selected channel.
Deskew compensates delay differences between channels caused by the different
length of cables, probes, and other sources.
Suffix:
<m>
.
1|2 (RTH1002) , 1..4 (RTH1004)
Parameters:
<Deskew> Deskew value
Range: -100E-9 to 100E-9
Increment: 800E-12
*RST: 0
Default unit: s
CHANnel<m>:THReshold:TECHnology <ThresholdType>
Sets the threshold value for digitization of analog signals. If the signal value is higher
than the threshold, the signal state is high (1 or true for the boolean logic). Otherwise,
the signal state is considered low (0 or false) if the signal value is below the threshold.
Suffix:
<m>
.
1|2 (RTH1002) , 1..4 (RTH1004)
Parameters:
<ThresholdType> TTL | ECL | CMOS | CAN | GND | LIN7vsupply | LIN12vsupply |
LIN18vsupply | USER
TTL
1.4 V
Waveform Setup
