Remote Control Commands
R&S
®
Scope Rider RTH
330User Manual 1326.1578.02 ─ 12
TRIGger:TIMeout:RANGe <TimeoutMode>
Selects the relation of the signal level to the trigger level, which is specified with
TRIGger:LEVel<m>:VALue
Parameters:
<TimeoutMode> HIGH | LOW | EITHer
*RST: HIGH
TRIGger:TIMeout:TIME <Time>
Sets the time limit for the timeout at which the instrument triggers.
Parameters:
<Time> Range: 100E-12 to 10000
Increment: 100E-9
*RST: 5E-9
Default unit: s
15.3.5.14 Interval Trigger (R&S RTH-K19)
TRIGger:INTerval:SLOPe................................................................................................330
TRIGger:INTerval:RANGe............................................................................................... 330
TRIGger:INTerval:WIDTh................................................................................................ 331
TRIGger:INTerval:DELTa.................................................................................................331
TRIGger:INTerval:MINWidth............................................................................................ 331
TRIGger:INTerval:MAXWidth...........................................................................................331
TRIGger:INTerval:SLOPe <Slope>
Sets the edge direction for the trigger. You can analyze the inteval between positive
edges or between negative edges.
Parameters:
<Slope> POSitive | NEGative
*RST: POSitive
TRIGger:INTerval:RANGe <Condition>
Defines how the time range of an interval is defined.
Parameters:
<Condition> LONGer | SHORter | EQUal | NEQual | WITHin | OUTSide
LONGer | SHORter
Triggers on intervals shorter or longer than an interval that is set
using TRIGger:INTerval:WIDTh.
