Data Logging
R&S
®
Scope Rider RTH
166User Manual 1326.1578.02 ─ 12
Remote command:
LOGGer:ZOOM:POSition on page 421
8.5.3 Logger Statistics
Figure 8-8: Logger statistics
1 = Measurement results; display depends on the logger mode and the selected measurement
2 = Mean value statistic
3 = Standard deviation statistic
Statistics are only shown if a single log is displayed.
Remote commands for logger statistics:
●
LOGGer:RECording:STARt? on page 421
●
LOGGer:RECording:TOTal? on page 422
●
LOGGer:MEASurement<m>:RESult:CURRentsampl? on page 422
●
LOGGer:MEASurement<m>:RESult:MAXimum:POSition? on page 422
●
LOGGer:MEASurement<m>:RESult:MAXimum:VALue? on page 422
●
LOGGer:MEASurement<m>:RESult:MINimum:POSition? on page 423
●
LOGGer:MEASurement<m>:RESult:MINimum:VALue? on page 423
●
LOGGer:MEASurement<m>:RESult:MEAN? on page 423
●
LOGGer:MEASurement<m>:RESult:STDDev? on page 423
●
LOGGer:MEASurement<m>:ENABled? on page 424
●
LOGGer:MEASurement<m>:TYPE? on page 424
●
LOGGer:MEASurement<m>:SOURce? on page 424
8.6 Export of Logger Records
Export means to save a logger record (slot) to a CSV or MAT file for further analysis.
Export is only possible if the instrument is in "Logger" mode. The instrument always
saves the data of the last saved slot, you cannot select the slot to be stored.
You can also save the data of the measured waveforms when you are in logger mode.
The waveform data has no time correlation to the logger data. For details of waveform
export, see Chapter 12.4, "Waveforms", on page 270.
Export of Logger Records
