User Manual Roth EnergyLogic Touchline/Wireless
Commissioning and operation
54 P100011294 E
Second wireless room
thermostat, set sensor
mode
► Press the sensor buttons
und of the wireless room thermostat for
10 seconds simultaneously.
► The display shows "– – – –" first permanently for 5 seconds and then blinks
for another 5 seconds.
► The display shows SENS.
NOTE
Sensor buttons and are inactive when the wireless room thermostat
is set in sensor mode. The setpoint can only be changed at the wireless
room thermostat which is in operation mode.
However, configuration of parameters can still be done by pressing the
sensor button
.
Address second wireless
room thermostat as tem-
perature sensor
► Press push button CH 1 of the wireless connection module.
► The corresponding LED CH 1 blinks.
► Press the sensor buttons
and of the second wireless room thermostat
for 5 seconds simultaneously.
► LED CH 1 of the wireless connection module lights.
► After 5 seconds LED CH 1 goes off.
► The display of the second wireless room thermostat shows the symbol
.
A second wireless room thermostat has been addressed to radio channel
CH 1, the first which is in sensor mode. Up to 5 units in sensor mode can be
assigned to one radio channel.
NOTE
It is possible to configure a wireless room thermostat with IR sensor also in
the "temperature sensor" mode. In the "temperature sensor" mode the
measured room temperature of the internal sensors are averaged. The
measured floor temperatures of the IR sensors are not averaged.
Revoke sensor mode
If the wireless room thermostat has not been assigned to any wireless control-
ler yet, revoke sensor mode as follows:
► Press the sensor buttons
and of the wireless room thermostat simul-
taneously for 10 seconds.
If the wireless room thermostat has already been assigned to a wireless
controller, revoke sensor mode according to either version A or B.
Version A
► Select parameter P-24, Option 4 of the service menu. See parameter
description P-24, page 83.
The wireless room thermostat will be reset to factory settings. The assign-
ment of the wireless room thermostat in sensor mode will be deleted.
