Ruijie Reyee RG-RAP Series

Web-based Configuration Guide System Settings
179
a Click Add in the SNMP v1/v2c Community Name List pane.
b Enter the group name, access mode, and view in the pop-up window.
c Click OK.
2. Configuring SNMP v3
 Application Scenario
You need to monitor and control devices, and use the third-party software to monitor
and deliver device information to public nodes (1.3.6.1.2.1). The security level of v3 is
authentication and encryption.
 Configuration Specification
According to the user’s application scenario, the requirements are shown in the following
table:
Table 5-7 User Requirement Specification
Item
Description
View range
Included rule: the OID is .1.3.6.1.2.1, and the custom view
name is “public_view”.
Group configuration
Group name: group
Security level: authentication and encryption
Select public_view for a read-only view.
Select public_view for a read & write view.
