SAME SILVER 80 - Page 237

Menu 1. 7
Menu 1. 6
S+L+H S.p.A.
( D ) ERASE LIST
LIST OF ALARMS
( E ) EXIT
S+L+H S.p.A.
CURRENT = 152
NEW = 168
STRAIGHTEN
WHEELS AND PRESS ( E )
CALIB. STEERING
( E ) EXIT
The DATA MONITOR can be used to select wheelslip "LIMITS" by way of the wheelslip table video page (refer to
the relative chapter “DATA MONITOR” for directions on how to access the table).
Selecting the type of soil and the type of wheelslip, the corresponding values stored in memory (and indicated in
the table) are adopted automatically, and cannot be changed manually.
WHEELSLIP TABLE
LIGHT SOIL NORMAL SOIL HEAVY SOIL
Wheelslip Main Secondary Main Secondary Main Secondary
Min. 70 35 65 35 60 40
Med. 65 45 60 50 50 55
Med. / Max. 60 60 50 65 45 70
Max 40 70 45 75 40 75
59
5
vehicle
electronic power-lift
237
