Display of alarm code.
To enable swift identification of the type of alarm triggered, the triangle blinks in such a way as to generate code
numbers, each associated with an exact alarm condition.
A code number is indicated as follows:
—triangle alight continuously for 2 seconds
—successive blinks of 0.3 s duration corresponding to tens
—triangle alight continuously for 0.8 s
—successive blinks of 0.3 s duration corresponding to units
—repetition of cycle until alarm deactivates.
ALARM CODES TABLE
Codes Description of alarm Type of alarm
11 EPROM (Program Memory), Immobilizing alarm
immobilizing alarm
12 Position control sensor disconnected
13 Up and/or down solenoid valve short circuit
14 Up solenoid valve disconnected
15 Down solenoid valve disconnected
21 Internal fault at control unit
22 Position control sensor incorrectly set
23
24
25
31 Draft control sensor disconnected
warning alarm
32 Draft control sensor not correctly set
33 Wheel speed sensor faulty
34 RADAR fault
35 EPROM fault (CPU data memory)
41
42
43
44
45
51 Steering sensor disconnected
52
53
54 Wrong wheel constant
55 Wrong RADAR constant
59
5
vehicle
electronic power-lift
238
