controls
hydrostatic steering
15 - Insert the distributor from the bottom
trying to make installation easier alter-
nately rotating in both directions.
16 - Press the distributor until the plug is
pushed out of the opposite side.
17 - Turn the distributor case upside
down holding the rotary distributor in
place and iserting the shunt valve as
indicated by the arrow in figure.
18 - Screw down the valve grub screw
in its seat.
19 - Insert the balls as shown by the
arrow.
20 - Insert the two pins in the same
positions as previously shown.
21 - Fit the seal ring in the related seat. 22 - Fit the spacer in such a way the
holes in it are in the same line as the
corresponding grooves.
23 - Insert the drive shaft in the distribu-
tor so that the notching may engage into
the pin in a position being parallel to the
distributor face.
12 - O-ring as installed on the plug. 13 - Insert the O-ring into the sleeve and
press until it is fully inserted.
14 - Pull out the tool.
63
6
298
