SAME SILVER 80 - Page 463

LIST OF ALARMS
CODES MESSAGE on the TESTER DESCRIPTION
11 "EvL State No OK" Failure of the low range Elecro-valve
12 "EvL ShortCircuit" Short-Circuit of the low range Electro-valve
13 "EvL Open Circuit" Disconnected low range Electro-valve
14 "Sens. RPM Open" Disconnected engine speed sensor
15
"Sns.Tmp Oil Open" Disconnected oil temperature sensor
"Sns.Tmp Oil S.C." Short-Circuit oil temperature sensor
16
"Direct.Lev. Open" Disconnected direction commands on the armrest
"Direct.Lev. S.C." Short-Circuited direction commands on the armrest
"Direct.Lev. N. V." Disconnected direction commands on the armrest
21 "EvM State No OK" Failure of the medium range Elecro-valve
22 "EvM ShortCircuit" Short-Circuit of the medium range Electro-valve
23 "EvM Open Circuit" Disconnected medium range Electro-valve
24 "Sens.Wheel Open" Disconnected speed sensor
25 "Display Fault"
Disconnected or broken led bar. This message is only dys
-
played by the tester
26
"SteeringN/C Open" Consent/neutral command signal disconnected
"SteeringN/C S.C." Consent/neutral command signal short-circuited
31 "EvH State No OK" Failure of the high range Elecro-valve
32 "EvH ShortCircuit" Short-Circuit of the high range Electro-valve
33 "EvH Open Circuit" Disconnected high range Electro-valve
34 "Sens. Revrs Open" Disconnected inverter speed sensor
35
"Pos. Pedal open" Disconnected clutch pedal sensor
"Pos.Ped.S.C./Open" Disconnected or short-circuited clutch pedal sensor
"Pos. Pedal N.V." Broken clutch pedal sensor
36
"SteeringF/B Open" Direction command signal disconnected
"SteeringF/B S.C." Direction command signal short-circuited
"SteeringF/B N.V." Broken direction command button
41 "HML+ButtonPushed" Damaged HML increase button
