VI
Transmission
Hydrive
3
31
F = 000 0 MURN 4 0
Fill Oil TMPK 1.32
Filling RPMK 1.10
( 1 ) F 1 4) 5) 6) 7) SF
PRX . CLU. FWD . 07.8
PRX . CLU . REV. 08.0
( 2 ) F 2 9) A / M
ADI . CLU. FWD. 0.49
ADI . CLU. REV. 08.0
( F ) SAVE DATA A) - B) + C) - D) +
CORRECTION 01090
FILLG. TIME 00000
EVP - CURRNT 00000
( E ) EXIT
SHUTTLE CALIBRATION
( E ) EXIT
SHUTTLE CALIBRATION
F = 000 O ALRN 4 0
Fill Oil TMPK 1.32
Filling RPMK 1.10
PRX . CLU. FWD. 07.8
PRX . CLU. REV. 08.0
ADI . CLU. FWD. 0.49
ADI . CLU. REV. 08.0
CORRECTION 01090
FILLG. TIME 00000
EVP - CURRNT 00000
EXIT
- LEVEL
- 1500 RPM
- OIL Tmp. = 35 G.C.
- NORMAL RANGE
- GEAR 2nd H
PRESS KEY AND THEN SELECT DI
-
RECTION FOR CALIBRATION!
WAIT UNTIL MACHINE MOVES OFF
THEN SELECT NEUTRAL!
( E ) EXIT
END OF CALIBRATION
COMPLETED OK !
PRX . CLU. FWD. 05.5
PRX . CLU. REV. 05.5
ADI . CLU. FWD. 0.60
ADI . CLU. REV. 0.60
SET TRACTOR
- LEVEL
- 1500 RPM
- OIL Tmp. = 35G.C.
- NORMAL RANGE
- GEAR 2nd H
SET TRACTOR
PRESS KEY
CALIBRATION MENU
1 - MANUAL CALIBRATION
2 - AUTOMATIC CALIBRATION
( E ) EXIT
ALARM LIST
(FROM MOST RECENT)
NO ALARM
(C) CANCEL ALARM
( E ) EXIT
/ - CONTROL - STG
| FWD
\ - - _C_/_F_- |_ _REV
|
CLU. PED. | - - - - - -
SW - | | C.B -
PS - | - - - - - -
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
JOYSTK.
/ - - - - - - - - / - - - - - -
:FWD: | HML +
:REV: | HML +
: - - - - - : \ - - - - -
: - CNS - :
( E ) EXIT
DIAGNOSTICS
(IN ORDER OF PRIORITY)
NO ALARM
