Satec PM174 User Manual

35
Address Point ID Description
Low and High Scales
3
Units
3
Type R/W Notes
+11 0x6F0B Reserved 0 UINT16 R
+12 0x6F0C I1 Inter-harmonics THD 0-999.9 0.1% UINT16 R
+13 0x6F0D I2 Inter-harmonics THD 0-999.9 0.1% UINT16 R
+14 0x6F0E I3 Inter-harmonics THD 0-999.9 0.1% UINT16 R
+15 0x6F0F Reserved 0 UINT16 R
+16 0x6F10 I1 TDD 0-100.0 0.1% UINT16 R
+17 0x6F11 I2 TDD 0-100.0 0.1% UINT16 R
+18 0x6F12 I3 TDD 0-100.0 0.1% UINT16 R
NOTES:
1
When the 4LN3, 4LL3, 3LN3, 3LL3, 3BLN3 or 3BLL3 wiring mode is selected, the voltages will be line-to-neutral; for any other wiring mode, they will be line-to-line.
2
When the 4LN3, 3LN3 or 3BLN3 wiring mode is selected, the voltages will be line-to-neutral; for any other wiring mode, they will be line-to-line voltages.
3
For volts, amps, power and frequency scales and units refer to Section 4 ”Data Scales and Units”. For analog data scaling formulas and examples, see Section 2.6.1, “16-bit Scaled Integer
Format”.
4
Harmonic angles are referenced to the fundamental voltage harmonic H01 on phase L1.
5
On a 0.2-s interval.
6
On a 3-s interval.
