Satec PM174 User Manual

37
Address Point ID Description
Options/Range
3
Units
3
Type R/W Notes
+24,25 0x0C0C kVA L1 0-Pmax U3 UINT32 R
+26,27 0x0C0D kVA L2 0-Pmax U3 UINT32 R
+28,29 0x0C0E kVA L3 0-Pmax U3 UINT32 R
+30,31 0x0C0F Power factor L1 -1000-1000
×0.001
INT32 R
+32,33 0x0C10 Power factor L2 -1000-1000
×0.001
INT32 R
+34,35 0x0C11 Power factor L3 -1000-1000
×0.001
INT32 R
+36,37 0x0C12 V1/V12 Voltage THD 0-9999
×0.1%
UINT32 R
2, 5
+38,39 0x0C13 V2/V23 Voltage THD 0-9999
×0.1%
UINT32 R
2, 5
+40,41 0x0C14 V3/V31 Voltage THD 0-9999
×0.1%
UINT32 R
2, 5
+42,43 0x0C15 I1 Current THD 0-9999
×0.1%
UINT32 R
5
+44,45 0x0C16 I2 Current THD 0-9999
×0.1%
UINT32 R
5
+46,47 0x0C17 I3 Current THD 0-9999
×0.1%
UINT32 R
5
+48,49 0x0C18 I1 K-Factor 10-9999
×0.1
UINT32 R
5
+50,51 0x0C19 I2 K-Factor 10-9999
×0.1
UINT32 R
5
+52,53 0x0C1A I3 K-Factor 10-9999
×0.1
UINT32 R
5
+54,55 0x0C1B I1 Current TDD 0-1000
×0.1%
UINT32 R
5
+56,57 0x0C1C I2 Current TDD 0-1000
×0.1%
UINT32 R
5
+58,59 0x0C1D I3 Current TDD 0-1000
×0.1%
UINT32 R
5
+60,61 0x0C1E V12 Voltage 0-Vmax U1 UINT32 R
+62,63 0x0C1F V23 Voltage 0-Vmax U1 UINT32 R
+64,65 0x0C20 V31 Voltage 0-Vmax U1 UINT32 R
13696-13703 1-Cycle Total Values
+0,1 0x0F00 Total kW -Pmax-Pmax U3 INT32 R
+2,3 0x0F01 Total kvar -Pmax-Pmax U3 INT32 R
+4,5 0x0F02 Total kVA 0-Pmax U3 UINT32 R
+6,7 0x0F03 Total PF -1000-1000
×0.001
INT32 R
+8,9 0x0F04 Total PF lag 0-1.000
×0.001
UINT16 R
+10,11 0x0F05 Total PF lead 0-1.000
×0.001
UINT16 R
+12,13 0x0F06 Total kW import 0-Pmax U3 UINT32 R
+14,15 0x0F07 Total kW export 0-Pmax U3 UINT32 R
+16,17 0x0F08 Total kvar import 0-Pmax U3 UINT32 R
+18,19 0x0F09 Total kvar export 0-Pmax U3 UINT32 R
+20,21 0x0F0A 3-phase average L-N/L-L voltage 0-Vmax U1 UINT32 R
1
+22,23 0x0F0B 3-phase average L-L voltage 0-Vmax U1 UINT32 R
+24,25 0x0F0C 3-phase average current 0-Imax U2 UINT32 R
13824-13833 1-Cycle Auxiliary Values
+0,1 0x1000 Not used UINT32 R
+2,3 0x1001 In (neutral) Current 0-Imax U2 UINT32 R
+4,5 0x1002 Frequency 0-Fmax
×0.01Hz
UINT32 R
+6,7 0x1003 Voltage unbalance 0-3000
×0.1%
UINT32 R
+8,9 0x1004 Current unbalance 0-3000
×0.1%
UINT32 R
13888-13919 Phasor
+0,1 0x1080 V1/V12 Voltage magnitude 0-Vmax U1 UINT32 R
2
