Satec PM174 User Manual

53
Address Point ID Description
Options/Range/Format
2
Units
2
Type R/W Notes
+98,99 Timestamp sec UINT32 R
+100,101
+102,103
0x3419 Max. I2 K-Factor
Timestamp
10-9999
×0.1
sec
UINT32
UINT32
R
R
3
+104,105
+106,107
0x341A Max. I3 K-Factor
Timestamp
10-9999
×0.1
sec
UINT32
UINT32
R
R
3
+108,109
+110,111
0x341B Max. I1 Current TDD
Timestamp
0-1000
×0.1%
sec
UINT32
UINT32
R
R
3
+112,113
+114,115
0x341C Max. I2 Current TDD
Timestamp
0-1000
×0.1%
sec
UINT32
UINT32
R
R
3
+116,117
+118,119
0x341D Max. I3 Current TDD
Timestamp
0-1000
×0.1%
sec
UINT32
UINT32
R
R
3
37120-37135 Maximum Total Values
+0,1
+2,3
0x3500 Max. Total kW
Timestamp
-Pmax-Pmax U3
sec
INT32
UINT32
R
R
+4,5
+6,7
0x3501 Max. Total kvar
Timestamp
-Pmax-Pmax U3
sec
INT32
UINT32
R
R
+8,9
+10,11
0x3502 Max. Total kVA
Timestamp
0-Pmax U3
sec
UINT32
UINT32
R
R
+12,13
+14,15
0x3503 Max. Total PF
Timestamp
-1000-1000
×0.001
sec
INT32
UINT32
R
R
37376-37387 Maximum Auxiliary Values
+0,1
+2,3
0x3600 Not used UINT32
UINT32
R
R
+4,5
+6,7
0x3601 Max. In Current
Timestamp
0-Imax U2
sec
UINT32
UINT32
R
R
+8,9
+10,11
0x3602 Max. Frequency
Timestamp
0-Fmax
×0.01Hz
sec
UINT32
UINT32
R
R
37504-37535 Billing Summary Maximum Demands
+0,1
+2,3
0x4780 Summary register #1 Maximum Demand
Timestamp
0-Pmax U3 UINT32 R
+4,5
+6,7
0x4781 Summary register #2 Maximum Demand
Timestamp
0-Pmax U3 UINT32 R
…
+28,29
+30,31
0x4783 Summary register #8 Maximum Demand
Timestamp
0-Pmax U3 UINT32 R
37632-37695 Maximum Demands
+0,1
+2,3
0x3700 V1/V12 Maximum volt demand
Timestamp
0-Vmax U1
sec
UINT32
UINT32
R
R
1
+4,5
+6,7
0x3701 V2/V23 Maximum volt demand
Timestamp
0-Vmax U1
sec
UINT32
UINT32
R
R
1
+8,9
+10,11
0x3702 V3/V31 Maximum volt demand
Timestamp
0-Vmax U1
sec
UINT32
UINT32
R
R
1
+12,13
+14,15
0x3703 I1 Maximum ampere demand
Timestamp
0-Imax U2
sec
UINT32
UINT32
R
R
