Satec PM174 User Manual

56
Address Point ID Description
Options/Range/Format
2
Units
2
Type R/W Notes
+4,5
+6,7
0x4981 Tariff #2 maximum demand
Timestamp
0-Pmax U3
sec
UINT32
UINT32
R
R
… R
+28,29
+30,31
0x4987 Tariff #8 maximum demand
Timestamp
0-Pmax U3
sec
UINT32
UINT32
R
R
38784-38815 Billing TOU Maximum Demand Register #6
+0,1
+2,3
0x4A80 Tariff #1 maximum demand
Timestamp
0-Pmax U3
sec
UINT32
UINT32
R
R
+4,5
+6,7
0x4A81 Tariff #2 maximum demand
Timestamp
0-Pmax U3
sec
UINT32
UINT32
R
R
… R
+28,29
+30,31
0x4A87 Tariff #8 maximum demand
Timestamp
0-Pmax U3
sec
UINT32
UINT32
R
R
38912-38943 Billing TOU Maximum Demand Register #7
+0,1
+2,3
0x5300 Tariff #1 maximum demand
Timestamp
0-Pmax U3
sec
UINT32
UINT32
R
R
+4,5
+6,7
0x5301 Tariff #2 maximum demand
Timestamp
0-Pmax U3
sec
UINT32
UINT32
R
R
… R
+28,29
+30,31
0x5307 Tariff #8 maximum demand
Timestamp
0-Pmax U3
sec
UINT32
UINT32
R
R
39040-39071 Billing TOU Maximum Demand Register #8
+0,1
+2,3
0x5380 Tariff #1 maximum demand
Timestamp
0-Pmax U3
sec
UINT32
UINT32
R
R
+4,5
+6,7
0x5381 Tariff #2 maximum demand
Timestamp
0-Pmax U3
sec
UINT32
UINT32
R
R
… R
+28,29
+30,31
0x5387 Tariff #8 maximum demand
Timestamp
0-Pmax U3
sec
UINT32
UINT32
R
R
NOTES:
1
When the 4LN3, 3LN3 or 3BLN3 wiring mode is selected, the voltages will be line-to-neutral; for any other wiring mode, they will be line-to-line voltages.
2
For volts, amps, power and frequency scales and units, refer to Section 4 ”Data Scales and Units”.
3
On a 0.2-s interval.
