44 Programming SATEL
Required settings of the INT-GSM / INT-GSM LTE module for all methods of establishing
connection:
• COMMUNICATION WITH DLOADX option enabled,
• data encryption key (DLOADX KEY) programmed,
• configured Internet connection settings.
Initiating connection from the keypad
Required settings of the INT-GSM / INT-GSM LTE module:
• programmed: address of computer with DLOAX program (DLOADX SERVER) and number
of TCP port used for communication.
Required settings of the DLOADX program for direct communication with the module:
• programmed: number of TCP port used for communication and data encryption key
(DLOADX KEY) or selected set of parameters “GSM: INT-GSM, Address n” (settings of the
INT-GSM / INT-GSM LTE module with address “n” will be used).
1. Click on the button in the DLOADX program.
2. A drop-down menu will be displayed. Select “TCP/IP: DLOADX <- ETHM/INT-GSM” in it.
3. In the LCD keypad connected to the control panel, start the INT-GSM DLOADX function
([code] DOWNLOADING INT-GSM DLOADX). The function is available to the
installer, administrator and the user having the DOWNLOADING STARTING right.
4. The DLOADX program will inform you about establishing connection by means of
a suitable message.
Initiating connection by SMS message
Required settings of the INT-GSM / INT-GSM LTE module:
• programmed: address of computer with DLOAX program (DLOADX SERVER) and number
of TCP port used for communication,
• programmed control command, which, if sent in the SMS message, will initiate connection
with the DLOADX program.
Required settings of the DLOADX program for direct communication with the module:
• programmed: number of TCP port used for communication and data encryption key
(DLOADX KEY) or selected set of parameters “GSM: INT-GSM, Address n” (settings of the
INT-GSM / INT-GSM LTE module with address “n” will be used).
1. Click on the button in the DLOADX program.
2. A drop-down menu will be displayed. Select “TCP/IP: DLOADX <- ETHM/INT-GSM” in it.
3. Send to the INT-GSM / INT-GSM LTE module the following SMS message:
xxxx= („xxxx” – the control command to initiate establishment of communication with
DLOADX program) – the module is to connect to the computer address programmed in
the module,
xxxx=aaaa:p= („xxxx” – the control command to initiate establishment of communication
with DLOADX program; „aaaa” – address of the computer with DLOADX program (IP
address or domain name); „p” – TCP port) – the module is to connect to the computer
whose address has been given in the SMS message and use for communication the
TCP port given in the SMS message.
4. The DLOADX program will inform you about establishing connection by means of
a suitable message.
