SATEL INTEGRA 65
48...63 VOICE MESSAGE 0...15 – activated by the telephone messaging function. It enables any
external device to be used for playback of notification messages. When programming the
telephone messaging, the number of message to be played back is to be programmed.
The messaging will turn on the corresponding output.
64...79 REMOTE SWITCH 1...16 – intended for control using the telephone (DTMF). The control
is available to the users having a telephone code. Additionally, the outputs can be
controlled using the user OUTS CONTROL function (see: USER MANUAL).
If an output of the REMOTE SWITCH type is to be controlled from the keypad, it must be
assigned to a group of outputs (see: “Output groups” p. 69).
If a cut-off time has been programmed for a REMOTE SWITCH type output, the output will
operate similarly to the 24. MONO SWITCH type output.
80. NO GUARD TOUR – indicates lack of guard tour.
81. AC LOSS (MAINBOARD) - LONG – indicates the loss of AC power supply to the control panel
mainboard, when the trouble lasts long enough to be saved to the event log (see: AC LOSS
REPORT DELAY
parameter p. 77).
82. AC LOSS (EXPANSION MODULE) - LONG – indicates the loss of AC power supply to the
modules with power supply unit, when the trouble lasts long enough to be saved to the
event log (the delay is programmed individually in each module).
83. OUTPUTS OFF – the output activates when all selected outputs stop signaling.
84. ACCESS CODE ENTERING – indicates the entering the user code.
85. USE OF ACCESS CODE – indicates the using a code (e.g. for system arming/disarming).
86. DOOR OPEN INDICATOR – indicates the opening the door supervised by a module executing
the access control functions.
87. DOOR TOO LONG OPENED INDICATOR – indicates the long open door supervised by a module
executing the access control functions.
88. BURGLARY ALARM (NO FIRE AND TAMPER) – signals burglary alarms and PANIC alarms from
keypads.
89. 50% OF LOG MEMORY FILLED – informs that 50% of the event log area has been filled since
the last event log reading with the DLOADX program.
90. 90% OF LOG MEMORY FILLED – informs that 90% of the event log area has been filled since
the last event log reading with the DLOADX program.
91. AUTO-ARM DELAY START – signals starting the AUTO-ARMING DELAY countdown for
a programmed time period (see: p. 49).
92. AUTO-ARM DELAY STATUS – indicates the AUTO-ARMING DELAY countdown (see: p. 49).
93. UNAUTHORIZED ACCESS – signals unauthorized opening of a door monitored by the module
executing access control functions.
94. ALARM – UNAUTHORIZED ACCESS – similarly as type 93, but the signaling only applies to
modules with enabled ALARM ON UNAUTH. ACCESS option.
95. IP REPORTING TROUBLE – signals troubles related to reporting via Ethernet and cellular
data network.
96. TELEPHONE LINE TROUBLE – informs about telephone communication troubles.
In the case of INTEGRA 128-WRL control panel, the output type 96 is called GSM
TROUBLES and indicates the GSM communication related troubles.
97. VOICE MESSAGE – similarly as types 48-63, but the numbers of synthesizers (messages)
must be selected.
98. REMOTE SWITCH – similarly as types 64-79, but the numbers of remote switches must be
selected.
