SATO CG2 Series User Manual

Section 3: Operation and Configuration
Page 3-10 CG2 Series Operator Manual
3.4 FACTORY TEST PRINT MODE (cont’d)
3.4.1 Output Data of the Factory Test Print
The output data of the Factory Test Print shows the internal operating parameters of the printer.
These output data are printed in three parts, each with the printing area of 60mm [2.36”] (Width) x 80mm
[3.15”] (Pitch), Standard.
First print-out (Settings)
No. Print Item Contents of the print data
1 Model Printer model name CG208TT(*), CG212TT(*)
CG208DT, CG212DT
*: “T” is printed for thermal
transfer print.
“D” is printed for direct
thermal print.
2 Firm Ver Printer F/W version 32.**.**.**
3 Firm Date Printer F/W creation date YY.MM.DD
4 Font Version Font version **.**(R)
5 CONT/USB Serial USB serial No. ********
6 Life Counter Life counter *.* Km
7 Head Counter1 Head counter 1 *.* Km
8 Head Counter2 Head counter 2 *.* Km
9 Head Counter3 Head counter 3 *.* Km
10 Cutter Counter Cutter counter *******
11 Head Check Head check result OK / NG
12 Thermistor Print head temperature ***
13 Sensor Type Sensor type I-Mark
Gap
Gap (Wrist Band)
None
14 Sensor Level Low Average minimum value of
pitch sensor
*.* V
15 Sensor Level High Average maximum value of
pitch sensor
*.* V
16 Sensor Slice Level Pitch sensor slice level *.* V
17 Pitch Offset[VR3] Print start position ±30 DOT [203dpi]
±45 DOT [305dpi]
18 Option Offset[VR3] Option stop position ±30 DOT [203dpi]
±45 DOT [305dpi]
19 FROM1 CHECK SUM Printer F/W: Font: Check
sum
(B)**** (P)****
(F)**** (A)****
20 LAN(WLAN) CHECK
SUM
LAN(WLAN) F/W check sum (B)**** (P)**** (A)****
