Section 6: General Specifications
CG2 Series Operator Manual Page 6-3
MODEL NAME
CG208 DT CG212 DT CG208 TT CG212 TT
MEDIA (Be sure to use media manufactured or certified by SATO)
Size
Non-adhesive paper/ Tag Non-adhesive paper/ Tag
Continuous
Cutter
Tear-off
Pitch
: 9 to 603 mm (0.35” to
23.74”)
Width
: 15 to 63 mm (0.59”
to 2.48”)
Pitch
: 25 to 603 mm (0.98”
to 23.74”)
Width
: 15 to 63 mm (0.59”
to 2.48”)
Pitch
: 15 to 603 mm (0.59”
to 23.74”)
Width
: 15 to 63 mm (0.59”
to 2.48”)
Continuous
Cutter
Tear-off
Pitch
: 9 to 403 mm (0.35” to
15.87”)
Width
: 15 to 63 mm (0.59” to
2.48”)
Pitch
: 25 to 403 mm (0.98”
to
15.87”
)
Width
: 15 to 63 mm (0.59” to
2.48”)
Pitch
: 15 to 403 mm (0.59”
to
15.87”
)
Width
: 15 to 63 mm (0.59” to
2.48”)
* The above size may be limited by use conditions, such as type of paper, usage
environment, and application.
* When using the dispenser mode, restrictions apply to the maximum paper length
according to paper installation conditions.
Thickness
0.06 to 0.19 mm (0.0024” to 0.0075”)
* The specification for wrist-band has to be confirmed individually.
RIBBON (Be sure to use ribbon manufactured or certified by SATO)
Wind Direction Face Out
Winding Method Paper core
Roll Diameter __ Maximum outer diameter: 38 mm (1.5”)
Core Diameter Inner core diameter: 12.7 mm (0.5”)
Width Max. 59mm (2.32”)
PROCESSING
CPU 32 Bit RISC-CPU 133MHz
Flash ROM 4 Megabytes
RAM 8 Megabytes
PRINTER LANGUAGE
Standard SATO Barcode Printer Language (SBPL)
INTERFACES
Standard Configurations
Select one of the following. (The factory will provide the unit with the selected
interface.)
1) USB 2.0(Type B) with RS-232C(D-sub 9-pin type) or
2) USB 2.0(Type B) with LAN(10BASE-T/100BASE-TX Automatic Switching)
*The RS-232C connector can be used to connect the printer to a computer or the
Keypad.
User installable Optional Inter-
face Board
Wireless LAN (802.11b/g Auto-switching) interface kit (External)
*Applicable to USB with RS232C model only
To Next Page
