Section 6: General Specifications
Page 6-6 CG2 Series Operator Manual
MODEL NAME
CG208 DT CG212 DT CG208 TT CG212 TT
HARDWARE AND RELATED
Operation keys POWER and FEED/LINE buttons
Indicators ON LINE (POWER): One (lights or flashes in two colors: green or red).
Potentiometer for adjustment
VR1 - Label Gap sensor adjustment/ Center tag hole sensor adjustment (Adjusts the
sensor slice level.)
VR2 - I-mark sensor adjustment (Adjusts the sensor slice level.)
VR3 - Cut position adjustment (Only applicable when cutter unit is installed.)
Label dispenser stop position adjustment (Only applicable when dispenser
unit is installed.)
Surface Treatment
Antibacterial finishing for external cover and operative parts.
Tested according to JIS Z 2801 standard
OPTIONS
1) Cutter Unit
2) Dispenser Unit
3) RFID kit (13.56 MHz)
4) External Unwinder Unit
5) Keypad
*Applicable to USB with RS232C model only. Connect to RS232C terminal.
6) Wireless LAN (802.11b/g Auto switch) interface kit (External)
*Applicable to USB with RS232C model only. Connect to USB terminal.
REGULATORY COMPLIANCE
Safety regulation CCC (GB4943-2001)
EMC regulation
FCC15B Class B (USA/Canada)
CE (EN55022, EN55024) (Europe)
CISPR22, CISPR24 (reference standard, Singapore)
GB9254-1998, GB17625.1(2003) (China)
KN22, KN24 (Korea)
Wireless
regulation
Wireless
LAN (2.45
GHz)
FCC15B/ FCC15C (USA/Canada)
R&TTE (EN300 328 V1.4:2003-04), (EN301 489 V1.4.1:2002-08) (Europe)
IDA TS SRD:2004 (Singapore)
SRRC (China)
MIC (Korea)
RFID (HF)
FCC15B/ FCC15C (USA/Canada)
R&TTE (EN300-330) (Europe)
IDA TS 10 (Singapore)
MIC (Korea)
Packing Drop Standard ISTA-2A
Environmental (RoHS)
Chromium: below 0.1%
Lead: below 0.1%
Mercury: below 0.1%
Cadmium: below 0.01%
Polybrominated Bipheny (PBB): below 0.1%
Polybrominated Diphenyl Ether (PBDE): below 0.1%
