Section 3: Operation and Configuration
Page 3-16 CG2 Series Operator Manual
3.8 DEFAULT SETTING MODE
When default setting mode is selected and executed in Operation Setting mode (refer to Section 3.5
Operation Setting Mode), the printer will reset to the default setting (factory preset) as listed below.
*1. To be connected by Port1024 and Port1025 (2 port connections) or Port 9100 (1 port connection)
Note:
LAN and Wireless LAN setting items cannot be reset to factory default even with the default setting mode.
No. Items to be reset Default value
1 Offset (V, H) Vertical = 0 dot, Horizontal = 0 dot
2 Pitch Offset 0 dot
3 Cut Offset 0 dot
4 Dispensing Offset 0 dot
5 Tear-Off Offset 0 dot
6 Label Size Pitch 4800 dot x Width 448 dot [203 dpi]
Pitch 4800 dot x Width 672 dot [305 dpi]
7 Print Speed 75 mm/sec (3 Inches/sec)
8 Print Darkness 5A
9 Sensor Type Gap
10 Kanji Code JIS
11 Paper End Search Roll
12 Zero Slash Enabled
13 Proportional Pitch Enabled
14 Initial Feed Disabled
15 Auto Feed Disabled
16 Operation mode Continuous - (No setting)
Tear Off - (No setting)
Cutter Mode 1 (Head position)
Dispenser Mode 1 (Head position)
17 Interface RS-232C Baud rate=19200 bps, Data bit=8 bit, Parity=None,
Stop bit=1 bit, Protocol=Protocol for driver
LAN Protocol for driver (ENQ response mode) *1
USB - (No initial setting)
18 Tear Off Waiting Time 1000ms
19 Head Check Range Normal range (Entire print area)
20 RFID Mode Disabled
To Next Page
