Section 6: General Specifications
CG2 Series Operator Manual Page 6-1
GENERAL SPECIFICATIONS
6.1 PRINTER BASIC SPECIFICATIONS
MODEL NAME
CG208 DT CG212 DT CG208 TT CG212 TT
PHYSICAL CHARACTERISTICS
Width 128 mm (5.04”)
Depth 235 mm (9.25”)
Height 173 mm (6.81”)
Weight 1.5 kg (3.3 lbs.) 1.6 kg (3.5 lbs.)
POWER SUPPLY (AC ADAPTER)
Input Voltage 100-240 V AC, +/-10%, 50/60 Hz (Full range)
Output Voltage 19 V DC, +/-5%, 3A
Power Consumption
At peak times: 40 Watts / 60 VA (at 30% printing ratio)
During standby: 2.5 Watts / 5.3 VA
* With input power voltage conditions: AC 100 V
ENVIRONMENTAL (EXCLUDING MEDIA)
Operating Temperature 0° to 35°C (32 to 95°F)
Storage Temperature -10° to 60°C (14 to 140°F)
Operating Humidity 30 to 80% RH, Non-condensing
Storage Humidity 15 to 85% RH, Non-condensing
PRINT
Method DT models: Direct Thermal only
TT models: Thermal Transfer and Direct
Thermal
Maximum Speed (selectable)
50, 75 or 100 mm/second
2, 3 or 4 Inches/second (Setting: 2, 3, 4)
*Print speed varies depending on the of media used.
Resolution
8 dots/mm (203
Dots Per Inch)
12 dots/mm (305
Dots Per Inch)
8 dots/mm (203
Dots Per Inch)
12 dots/mm (305
Dots Per Inch)
Maximum Print Width 56 mm (2.2”) 56 mm (2.2”) 56 mm (2.2”) 56 mm (2.2”)
Maximum Print Length 600 mm (23.6”) 400 mm (15.75”) 600 mm (23.6”) 400 mm (15.75”)
