SATO CG2 Series User Manual

Section 3: Operation and Configuration
CG2 Series Operator Manual Page 3-25
3.14 HEAD OVER-TEMPERATURE PROTECTION
When the head temperature exceeds 70 ºC (158 ºF), the head over-temperature protection will be activated
and the print operation will be paused until the temperature drops down to 55 ºC (131 ºF).
* Head temperature will be checked per label.
Print start
Recheck head temperature
(Lower than 55 ºC, 131 ºF?)
Head over-temperature
protection activated
Ongoing print operation
will be paused
ON LINE (POWER)
Print operation will
occur when the head
temperature
becomes lower than
70
º C (158 º F).
No print operation will
occur unless the
head temperature
becomes lower than
50
º C (131 º F).
Print processing
Recheck per
label
No
No
Yes
Yes
Green→Red→Off
Head temperature check
(Higher than 70 ºC, 158 ºF?)
