Section 4: Troubleshooting
CG2 Series Operator Manual Page 4-3
Option
Cutter Red x twice ->Off
(blinks in long
interval)
1) Cutter is not connected.
2) Cut operation was not
performed successfully.
1) Connect the cutter unit.
2) Set and feed the paper
again.
Warning
Buffer near full Green -> Red
(Lights in turn)
1) Free space for receive
buffer is low.
1) Pause the data transmis-
sion on the host side
and wait to have enough
buffer space.
Ribbon near end Green-> Red ->Off
(Blinks in turn)
1) Remaining amount of
ribbon is little.
1) Ribbon replacement.
Head over-heat
protection
Green -> Red -> Off 1) Goes over the limit of
print head temperature.
1) Automatically recovers
when print head temper-
ature drops down to
55ºC (131ºF) and below.
AC adapter
protect
Red-> Green -> Off 1) Going over the
maximum print ratio.
1) Automatically recovers
after pausing a certain
period of time.
Item Contents
ON LINE
(POWER) LED
Causes Corrective Actions
To Next Page
