6.5.5 PCD2.A410,8digitaloutputsfor0.5Aeach,electricallyisolated
Application
Outputmodule,electricallyisolatedfromtheCPU,with8MOSFETtransistoroutputs,
without short-circuit protection. Voltage range 5 … 32 VDC.
This module is not suitable for triggering the PCA2.D12/D14 display modules.
Technical data
Number of outputs: 8, electrically isolated
Output current: 1...500mA...2A(leakagecurrentmax.0.1mA)
In the voltage range 5 … 24 VDC, the load resistance should
notbelessthan48Ω
Total current per module: 4 A on 100% duty cycle
Operating mode: Sourceoperation(positiveswitching)
Voltage range: 5 … 32 VDC, smoothed
10 … 25 VDC, pulsed
Voltage drop: ≤0.4Vat0.5A
Output delay: Switch-ondelaytypically10μs
Switch-offdelaytypically50μs
(ohmicload5..500mA),longerwithinductiveload,because
of the protective diode.
Isolation voltage: 1000 VAC, 1 min.
Resistance to interference:
acc. to IEC 801-4
4 kV under direct coupling
2kVundercapacitivecoupling(wholetrunkgroup)
Internal current consumption:
(from+5Vbus)
1 … 24 mA
typ. 15 mA
Internal current consumption:
(fromV+bus)
0 mA
External current consumption: Load current
Terminals: Pluggable10-polescrewterminalblock(440548470),for
wires up to 1.5 mm²
